CONFIGURE

Mechanical Construction

Process Connection
Dimension
A
120 mm 2.36 inch
B
40 mm 1.57 inch
H1 (PM0, PH0))
222 mm 8.74 inch
H1 (SM0, SH0)
267 mm 2.36 inch
H1 (Pf0, PFT)
239 mm 2.36 inch
H2
208 mm 2.36 inch
H3
192 mm 2.36 inch
W (Temp. N1, NA with JM, J5 Box)
2 mm 2.36 inch
W (Temp. N1, NA with JM, SM Box)
30 mm 2.36 inch
W (Temp. E2, E3, H4)
100 mm 2.36 inch



Common Dimensions for all Construction Types

  • Standard blue aluminum terminal box, size = 125 x 80 x 57 mm (4.92 x 3.15 x 2.24 in)
  • Terminal boxes are supplied with an M25 x 1.5 cable entry and a polyamide compression cable gland fitting (for cable diameters 7 - 14 mm / 0.28 - 0.56 in). M20 x 1.5, 1⁄2” NPT, 3⁄4” NPT cable entries (without gland) are optionally available and must be ordered separately


Optionally available (see Part Number Code):
SS 316 box, size = 100 x 100 x 61 mm (3.94 x 3.94 x 2.40 in) – only with remote transmitter



Integral Transmitter Option
RHE45 transmitter in blue aluminum box. Dimensions as standard blue aluminum terminal box - see RHE45 datasheet for additional details. Manifold versions with RHE45 are available with Temperature N1, NA, E2; sealless versions only with N1, NA

Manifold design with thread connections

Parallel tube/dual path
Serial tube / single path

Process Connection

Dimension

Female Thread G 1/2”

60 mm 2.36 inch

Female Thread 1/2” NPT

60 mm 2.36 inch

Autoclave 3/8” MP - 9/16” - 18 UNF
Female Thread(1)

70 mm 2.76 inch



Process Connection

Dimension

Female Thread G 1/2”

60 mm 2.36 inch

Female Thread 1/2” NPT

60 mm 2.36 inch

Autoclave 3/8” MP - 9/16” - 18 UNF
Female Thread (1)

70 mm 2.76 inch



Weights and Shipping Dimensions
• Approx. weight for manifold construction sensor with threads: 2.9 kg / 6.4 lb
• Approx. weight for seal-less construction sensor with ½” 150# flanges: 3.8 kg / 8.4 lb
• Shipping carton size approx. 60 x 41 x 32 cm (24 x 16 x 13 in)
• Gross weight of seal-less construction meter with ½” 150# flanges and RHE28 transmitter approx. 11 kg / 24 lb
