Enclosure Material

Coated cast aluminum universal field mount enclosure

Enclosure Rating

IP65 / NEMA 4. Optionally IP66 / NEMA 4X

Ambient Temperature:

-20°C (optionally -40°C) to +60°C / -4°F (-40°F) to +140°F

(reduced visibility below -20°C)

Dimensions:

170 x 272 x 93 mm / 6.7 x 10.7 x 3.7 in

Display:

Large high contrast backlit LCD 128 x 24. Screen changes color to indicate warning or error

Weight:

2.4 kg / 5.3 lb

Operation

3 x front panel operator buttons for all menu navigation and settings

Sensor Connection:

Cage clamp terminals.  Cable available in lengths up to 100m for connection to remote sensor

Analog Outputs:

Up to 2 x 4-20mA outputs, active or passive, compl. to NAMUR NE-43

Digital Outputs:

Up to 2 x configurable status outputs (IEC60946)

Pulse/Freq/Status Outputs

Up to 2 x configurable pulse/frequency/status outputs (IEC60946), max. 10 kHz

Digital Inputs:

Up to 2 x configurable control inputs (to IEC60946)

Analog Input (optional):

1 x 4-20mA analog input (active) for two-wire pressure or density sensor

Power Supply

100–240 VAC (48 to 62 Hz), 5 W and/or 12–24 VDC ±10%, 4 W

Digital Data Communications:

Modbus RTU (RS485)
Connection to PC (USB) with Rheonik RHECom software
HART over analog output

Hazardous Area Approvals

ATEX / IECEx: RHE in ordinary locations or Zone 2, RHM in all zones

cCSAus: RHE in ordinary locations or Division 2, RHM in all divisions (see datasheet)

Cable Entries

2 x M16, 2 x M20 as standard

Optional metric and NPT entries available
